Output: 15T/D

Product Advantages

1.The main structure is made of high strength stee and obtained patent certificate.

2.Rapid shear operation is achieved with fast hydraulic ScrapMetal Shearing Rang valve block assembly, 12 cuts per minute.

3.Optional single, continuous operation, can be equipped with diesel engine as power supply

Applications

It is suitable for small and medium‑sized scrap processing base, smelting and casting enterprises, non‑ferrous metal and other industries, and cold shear of various shapes of steel, metal profiles and metals of various structural parts, processing into qualified charge.

Tell us the material type, capacity and working conditions. We will recommend a matching model and send a quote.

REQUEST A QUOTE

Technical Parameters

Item	Parameter	Value
Shearing width		1000mm
Maximum Shearing Force		3600kn
Cutting Frequency		12 cuts/min
Electric Motor	Specification	YX3‑180L‑4/22KW
	Power	22KW
	Rated Speed	1475r/min
Hydraulic Pump	Specification	G160YCY14‑1B
Hydraulic Pump	Nominal Displacement	160 ml/r

Adopting our company’s latest‑generation patented R&D technology, combined with the structural amplification advantages of lever‑principle frame and exclusive hydraulic patent technology, this machine delivers fast shearing after material clamping. The cylinder bears cross‑force on the main shaft from top to bottom, featuring long cutting edge, large opening and powerful shearing performance.

Due to continuous product improvement, the above‑mentioned technical parameters shall be subject to the actual product. Our company reserves the right of final interpretation in case of any changes.
